Add Time： 2025-07-22 View：372
The induction melting of metallic materials is carried out mainly under vacuum or under protective atmosphere and is cast into the mould. This equipment is characterized by using the metal in the induction heating graphite crucible under the micro-negative pressure atmosphere. At the same time, it can add materials to mix the alloy components during the smelting process. After the metal is completely melted into liquid, rotate the electrode to cast it into the mould, and finally prepare the allo...
| main features |
Equipment structure | 1. Furnace body |
Equipment model | NBD-VAHP2000-1KG |
Maximum output power | 15KW |
Maximum current | 40A |
Induction coil, induction coil | φ79*φ62*72mm |
Quartz jacket | φ58*φ50*88.5mm |
Graphite crucible, graphite crucible | φ47*φ35*88.5mm |
Casting method | Hand cast casting |
Inflation pressure | ≤0.03MPa |
Vacuum Chamber Size | Φ315×313mm |
Service and Support | Year warranty with lifetime support (excluding consumable parts such as tubes and seals). |
