Equipment features:

1. Small size, light weight, can be directly put into the glove box in the large compartment. Does not take up laboratory space;

2. It can be used as a box furnace for heat treatment of large-size samples, and large-size quartz cavities are equipped with high-sealing vacuum flanges, which can sintering samples under vacuum or atmosphere conditions;

3. The use of advanced technology made of refractory insulation materials, small heat loss, effectively reduce equipment power;

4. Can meet a variety of material heat treatment sintering process.

Model

NBD-VAH1200-10CI

Electrical Spec

AC220V    1KW

System vacuum

Tmax

800℃

Heating rate

≤20℃/min

+/- 1℃

Chamber size

100*100*100mm

The support is placed in the matching cavity

Control system

1. Fuzzy PID temperature control, high light digital tube display;

2. The setting of 30 "time-temperature" curves can be realized through programming;

3. It has the functions of overtemperature alarm, broken couple warning, leakage protection and so on.

Temp Accuracy

+/- 1℃

  Effective volume of vacuum quartz reaction chamber:370ml（Φ74*100mm)

Net weight

Approx.12KG

Cautions

1. When the furnace temperature of the equipment is more than 300℃, do not open the reaction chamber to avoid damage;

2. Slight cracks caused by continuous use of the furnace are normal and do not affect the normal use of the equipment;

Service

1 year warranty with lifetime support (warranty does not include consumable parts).
