1. The heating element is distributed around the barrel -- the temperature field is more uniform;

2. Electric lifting platform design, easy and fast loading;

3. Compact vertical structure, reduce space occupation;

4 touch screen operation, intuitive display temperature curve - more simple operation.

Model

NBD-B1200-10TI

Electrical Spec

AC220V   1.4KW

Obtainable temp.

1200℃（<1 hour）

Max working temps.

1100℃

Heating rate

≤20℃/min

Chamber size

Φ90*70mm

Porcelain plate

Control system

1.NBD-101E embedded operating system Chinese and English interchangeable graphical interface, 7 inch true color touch screen input, intelligent man-machine dialogue mode, real-time heating power display, non-linear pattern temperature correction;

2. The system can store 15 curves, each of which can be set with 30 sections of "temperature-time" axis;

3. It has the functions of overtemperature alarm, broken couple prompt, leakage protection and so on.

Temp Accuracy

+/- 1℃

Heating element

Spiral heater Mo-doped Fe-Cr-Al alloy

Net weight

30KG

Cautions

1. Slight cracks caused by continuous use of furnace are normal phenomena and do not affect the normal use of equipment;

2. During the use of the equipment, please do not touch the tray when it falls in high temperature to avoid burns.

Service

1 year warranty with lifetime support (the warranty does not cover consumable parts, such as furnace tubes and sealing rings).
