Intelligent Chamber Furnace (7.2L) 1200°C

Release time: 2024-07-08 01:57:48  Number of views: 92

Equipment Introduction:
This equipment is specially processed and designed to fit the needs of customers, it is a medium temperature sintering furnace with high cost performance. Simplified classic design process, lightweight alumina fibre sintering chamber, touch screen control, man-machine dialogue, barrier-free communication, making the operation easier!



ProductBrief
ProductDetails
ProductVideo
MessageInquiry

Equipment Introduction:
This equipment is specially processed and designed to fit the needs of customers, it is a medium temperature sintering furnace with high cost performance. Simplified classic design process, lightweight alumina fibre sintering chamber, touch screen control, man-machine dialogue, barrier-free communication, making the operation easier!






Equipment features:
1、Furnace chamber volume size is moderate, suitable for a variety of materials heat treatment process;
2, the use of advanced technology made of refractory insulation materials, heat loss is small, effectively reducing the use of equipment power;
3, modular mechanism, durable and easy maintenance;
4、The top of the furnace is equipped with an exhaust chimney, effectively removing the volatiles produced during the sintering process;
5, touch screen operation, intuitive display of the temperature curve.

Product Model

NBD-M1200-20TI(B型)

Power supply specifications

AC220V  3.5KW

Reachable temperature

1200℃(<1小时)

continuous temperature

1100℃(连续)

Reachable heating rate

≤20℃/分钟

Furnace size

W200*H120*D300mm

Overall dimensions

W420*H530*D570mm

control system

1.NBD-101E embedded operating system in English and Chinese interchangeable graphical interface, 7 inches of true-colour touch screen input, intelligent man-machine dialogue mode, non-linear sample temperature correction;
2. 15 curves can be pre-stored, each curve can be set up 30 "time - temperature" node, eliminating the need to repeat the time to modify the curve;
3. With over-temperature alarm, broken even tips, leakage protection and other functions;

Temperature Accuracy

+/- 1℃

heating element

Mo-doped Fe-Cr-Al alloys

Atmosphere protection box
(Optional)


The Atmosphere Protection Box is an accessory device for use inside a heating furnace designed to create and maintain a specific atmosphere environment to protect the material being heated from oxidation, contamination, or undesirable reactions with other components of the air (custom sizes available).

net weight

约40KG

Precautions for the use of equipment

1. When the temperature of the furnace chamber of the equipment is ≥300℃, it is forbidden to open the furnace chamber to avoid being hurt;
2. The slight crack produced by the continuous use of the furnace chamber is a normal phenomenon, does not affect the normal use of the equipment;

Service Support

1 year warranty with lifetime support (consumable parts are not included in the warranty).
