Equipment Profile:
Roots vacuum pump referred to as Roots pump, it is the use of two 8-shaped rotor in the pump casing rotation and the role of suction and exhaust its principle and Roots blower similar. Roots pump in the low-pressure range of work, gas molecules larger free range, gas leakage through the small gap resistance is very high, you can obtain a higher compression ratio, can be used as booster vacuum pump.
technical specification
※ Equipment name: Roots pump unit
※ Power supply: three phase 380 V 50HZ
※ Frontal fixed power: 1.5KW
Maximum true space: 4 * 10-2pa
※ Size: 830 x 600 x 1100 mm
※ Weight: Approx. 100KG
When the Rotz pump is used in combination with the crude pump, the pumping speed of the crude pump can be improved when the pressure is lower than 1.3X10 ~ 1.3X10Pa (1X10 ~ 1X10Torr).
Note
1. The pump pressure is 0.03 MPa (0.3kg / cm). When the pressure of the exhaust end of the pump exceeds 0.03 MPa, please remove the gas that obstructs the airflow in time. The oil mist filter can be cleaned or replaced in time to keep the gas flowing smoothly.
2. The pump is not suitable for pumping flammable, explosive and toxic gases. When using a pump to pump out toxic gases, in addition to the pump, the pump oil is also toxic. Therefore, please pay special attention to maintenance and take corresponding protective measures according to the type of toxic gases.
3. This pump is not suitable for pumping gases with oxygen content greater than atmospheric oxygen content (oxygen content > 21%) or other highly reactive gases.
4. Do not use in places where there is a risk of explosion, so as not to cause personal injury or fire.
5. Please do not run the pump without refueling or insufficient oil, which is easy to cause wear of the pump and affect the performance and service life of the pump.
6. Always check the oil level when the pump is running.
7. The pump must work at an ambient temperature of 5 ~ 40 ° C. In order to ensure the effective heat dissipation of the pump, especially when the pump is installed in a closed system, the ambient temperature of the pump must not exceed 40 ° C.
