1. Desktop design, easy to move and operate;
2. Electric lifting platform, easy and fast loading. Annular heater, uniform temperature field;
3. Two layers of crucible can be placed at the same time;
4. Modular structure, durable and easy to maintain;
5. The top of the furnace is provided with an exhaust hole, and the dry pre-burning volatiles are swept away;
6. One-click operation is simple and convenient, pre-stored 15 working curves, as desired;
7. Real-time sintering temperature and power monitoring, safe power saving.

Model

NBD-B1600-12TI

Electrical Spec

AC220V   2.5KW

Tmax

1550℃

load mode

bottom-loading

Heating rate

≤20℃/min

Chamber size

Φ120*150mm

Control system

1. Can pre-store 15 denture sintering curves of various manufacturers, call at will. Each curve can be set 30 sections of "temperature-time" axis, avoiding the trouble caused by the repeated setting of different experimental processes;

2. It has the functions of overtemperature alarm, broken couple warning, leakage protection and so on.

Temp Accuracy

+/- 1℃

Heating element

Special high density silicon carbon heating element

Net weight

60KG

Cautions

If you want to sinter zirconium disks soaked with dye, be sure to dry the zirconium disks completely and then put them into the equipment for sintering to extend the service life of the equipment.

Service

1 year warranty with lifetime support (warranty does not cover consumable parts such as furnace tubes and seals).
