1. Special vaporization structure is adopted to ensure the stable generation of water vapor;
2. Adjustable gasification temperature;
3. Liquid flow controllable;
4. Steam transport preheating system to prevent steam condensation reflux;
5. Automatic feed, stepless speed regulation. Steam metering generation;
6. Easy to install, can be used with a variety of manufacturers pipe furnace.

Model

NBD-WTS101

Electrical Spec

AC220V    800W

Temp. regulation

Steam generation temperature 100℃~250℃ Pipe insulation temperature 120℃

High precision liquid delivery system

1. Speed range: 0.1·100rpm reversible reversible;
2. Speed resolution: 0.1rpm;
3. Speed regulation mode: film button;
4. Display mode: 4-bit LED display current speed or current flow;
5. Strengthen PP material, corrosion resistance;
6. Flow rate: 0.04-18ml/min;
7. Equipped with full speed key to achieve fast emptying and adding;
8. With power failure memory function, save running parameters in time.

control system

1. Fuzzy PID temperature control, high light digital tube display;
2. Programmable multi-stage "time-temperature" curve setting;
3. It has the functions of overtemperature alarm, broken couple warning, leakage protection and so on.

Temp Accuracy

+/- 1℃

Net weight

15KG

Service

Note: At 1 atmosphere, water expands by about 1244.44 times after vaporization at 100 degrees.

The water expanded by about 2,249.33 times after 180 degrees of vaporization

1 year warranty with lifetime support (warranty does not include consumable parts)
