Oscillating ball mill mixer

Release time: 2020-04-12 10:40:31  Number of views: 2298

High speed vibrating ball mill is a kind of high efficiency small instrument for preparing laboratory samples (small amount and trace amount). The instrument has three dimensional motion of rotating swing and vibration during grinding, the impact energy is higher than other types of ball mills, the instrument is small in size, light in weight, high in efficiency and cheap in price. It can be used for grinding, mixing and mechanical alloying of materials. The high speed vibrating ball mill can be used to ball mill or mix all kinds of solids, suspensions and pastes with different particle sizes and materials by dry and wet methods.


ProductBrief
ProductDetails
ProductVideo
MessageInquiry

High speed vibrating ball mill is a kind of high efficiency small instrument for preparing laboratory samples (small amount and trace amount). The instrument has three dimensional motion of rotating swing and vibration during grinding, the impact energy is higher than other types of ball mills, the instrument is small in size, light in weight, high in efficiency and cheap in price. It can be used for grinding, mixing and mechanical alloying of materials. The high speed vibrating ball mill can be used to ball mill or mix all kinds of solids, suspensions and pastes with different particle sizes and materials by dry and wet methods.





Main features:

Ø Small size, light weight and high efficiency;

Ø A high-performance small equipment for the preparation of laboratory samples (small amount, trace amount);

Ø It can be used for grinding and mixing of materials;

Ø Simple operation, reliable work, easy to clean;

No environmental pollution, can be dry, wet grinding;

Under the external force of vibration frequency 1000~3000 times/minute and amplitude 2~2mm, the original cracks on the surface of the material expand and produce new cracks, and the cracks will be crushed through the material particles.


Dry grinding: 1~2mm material →85~5um

Wet grinding: 1~2mm material →5~0.1um



  Basic parameter

Model

Can match ball mill tank specifications

Ball size(mm)

Feed size

discharging granularity

Oscillation frequency

real-time range(min)

power(AC220V)

boundary dimension (mm)

weight

(kg)

NBD-HLJ-I

50ml, 80ml

Φ10,Φ20

<1mm

The minimum is 0.1μm

1200R/min

0~999

180W

405*260*365

40


Disclaimer:

The product introduction content of this site (including product pictures, product descriptions, technical parameters, etc.) is for reference only. There may be some difference between the stated content and the actual situation due to the delay in updating. Please contact our customer service staff for confirmation. The information provided by this Site does not constitute any offer or acceptance. NOBODY will improve and modify any information on this site from time to time without prior notice.
