Variable frequency tablet press
Release time: 2020-04-12 10:09:45 Number of views: 1931
DYPJ series tablet presses are smaller, lighter, larger working space and more reliable pressure stability. The piston reciprocating stroke can output a certain pressure of liquid characteristics, so that the up and down shaking of the pressure can be suppressed, so that the pressure is faster and more labor-saving, improve work efficiency. And the main body of the instrument piston and mechanical pressure two parts of the independent structure, so that the future equipment cleaning and debugging process is more convenient, better facilitate the customer to maintain the instrument. It is mainly used in the experimental research fields of fine ceramic powder, superconductivity, building materials, new materials, green energy, etc., to press samples or other places where pressure needs to be applied. Especially suitable for use with calcium and iron analyzer, infrared spectrometer, X-ray fluorescence and other test instruments.
DYPJ series tablet presses are smaller, lighter, larger working space and more reliable pressure stability. The piston reciprocating stroke can output a certain pressure of liquid characteristics, so that the up and down shaking of the pressure can be suppressed, so that the pressure is faster and more labor-saving, improve work efficiency. And the main body of the instrument piston and mechanical pressure two parts of the independent structure, so that the future equipment cleaning and debugging process is more convenient, better facilitate the customer to maintain the instrument. It is mainly used in the experimental research fields of fine ceramic powder, superconductivity, building materials, new materials, green energy, etc., to press samples or other places where pressure needs to be applied. Especially suitable for use with calcium and iron analyzer, infrared spectrometer, X-ray fluorescence and other test instruments.
|
|
Main feature
|
|
|
|
基本参数
|
Model |
pressure range |
piston diameter(mm) |
Max piston stroke(mm) |
work space(mm) |
Pressure stability |
weight kg |
boundary dimension(mm) |
motor power（AC220V） |
|
BYPJ-20T |
0~20T（60Mpa) |
Ø80 |
20 |
105*105*105 |
≤0.1Mpa/min |
40 |
370*450*350 |
180W |
|
BYPJ-30T |
0~30T（60Mpa) |
Ø110 |
20 |
155*180*100 |
50 |
290*450*350 |
180W |
|
|
BYPJ-40T |
0~40T（60Mpa) |
Ø120 |
20 |
155*180*100 |
55 |
370*450*350 |
180W |
|
|
BYPJ-60T |
0~60T（60Mpa) |
Ø156 |
50 |
225*300*120 |
105 |
370*500*350 |
AC380V、270W |
|
|
* More models, welcome to inquire
Disclaimer: The content of product introduction (including product pictures, product descriptions, technical parameters, etc.) is for reference only. Due to the delay in updating, there may be some differences between the said content and the actual situation. Please contact our customer service staff for confirmation. The information provided on this site does not constitute any offer or commitment, and Nobadi will improve and modify any information on this site from time to time without prior notice.
|
||||||||
